GASKET DIMENSION FOR DIN 2690 STANDARD FLANGES
|
|
|
Dimension
Table (in mm)
Size |
Full Face |
|
Raised Face |
|
Full Face |
|
Raised face |
|
Full Face |
|
Raised Face |
|
Full Face |
|
Raised Face |
|
|
6 bar |
6 bar |
6 bar |
6 bar |
10 bar |
10 bar |
10 bar |
10 bar |
16 bar |
16 bar |
16 bar |
16 bar |
40 bar |
40 bar |
40 bar |
40 bar |
|
ID |
OD |
ID |
OD |
ID |
OD |
ID |
OD |
ID |
OD |
ID |
OD |
ID |
OD |
ID |
OD |
1/4" 10mm |
18 |
75 |
18 |
38 |
18 |
90 |
18 |
45 |
18 |
90 |
18 |
45 |
18 |
90 |
18 |
45 |
1/2" 15mm |
22 |
80 |
22 |
43 |
22 |
95 |
22 |
50 |
22 |
95 |
22 |
50 |
22 |
95 |
22 |
50 |
3/4" 20mm |
28 |
90 |
28 |
53 |
28 |
105 |
28 |
60 |
28 |
105 |
28 |
60 |
28 |
105 |
28 |
60 |
1" 25mm |
35 |
100 |
35 |
63 |
35 |
115 |
35 |
70 |
35 |
115 |
35 |
70 |
35 |
115 |
35 |
70 |
1 1/4" 32mm |
43 |
120 |
43 |
75 |
43 |
140 |
43 |
82 |
43 |
140 |
43 |
82 |
43 |
140 |
43 |
82 |
1 1/2" 40mm |
49 |
130 |
49 |
85 |
49 |
150 |
49 |
92 |
49 |
150 |
49 |
92 |
49 |
150 |
49 |
92 |
2" 50mm |
61 |
140 |
61 |
95 |
61 |
165 |
61 |
107 |
61 |
165 |
61 |
107 |
61 |
165 |
61 |
107 |
2 1/2" 65mm |
77 |
160 |
77 |
115 |
77 |
185 |
77 |
127 |
77 |
185 |
77 |
127 |
77 |
185 |
77 |
127 |
3" 80mm |
90 |
190 |
90 |
132 |
90 |
200 |
90 |
142 |
90 |
200 |
90 |
142 |
90 |
200 |
90 |
142 |
4" 100mm |
115 |
210 |
115 |
152 |
115 |
220 |
115 |
162 |
115 |
220 |
115 |
162 |
115 |
235 |
115 |
168 |
5" 125mm |
141 |
240 |
141 |
182 |
141 |
250 |
141 |
192 |
141 |
250 |
141 |
192 |
141 |
270 |
141 |
195 |
6" 150mm |
169 |
265 |
169 |
207 |
169 |
285 |
169 |
218 |
169 |
285 |
169 |
218 |
169 |
300 |
169 |
225 |
7" 175mm |
195 |
0 |
195 |
237 |
195 |
0 |
195 |
248 |
195 |
0 |
195 |
248 |
195 |
350 |
195 |
267 |
8" 200mm |
220 |
320 |
220 |
262 |
220 |
340 |
220 |
273 |
220 |
340 |
220 |
273 |
220 |
375 |
220 |
292 |
10" 250mm |
272 |
375 |
272 |
318 |
272 |
395 |
272 |
328 |
272 |
405 |
272 |
330 |
272 |
450 |
272 |
353 |
12" 300mm |
325 |
440 |
325 |
373 |
325 |
445 |
325 |
378 |
325 |
460 |
325 |
385 |
325 |
515 |
325 |
418 |
14" 350mm |
368 |
490 |
368 |
423 |
368 |
505 |
368 |
438 |
368 |
520 |
368 |
445 |
368 |
580 |
368 |
475 |
16" 400mm |
420 |
540 |
420 |
473 |
420 |
565 |
420 |
490 |
420 |
580 |
420 |
497 |
420 |
660 |
420 |
547 |
18" 450mm |
470 |
0 |
470 |
528 |
470 |
615 |
470 |
540 |
470 |
640 |
470 |
557 |
470 |
0 |
470 |
572 |
20" 500mm |
520 |
645 |
520 |
578 |
520 |
670 |
520 |
595 |
520 |
715 |
520 |
618 |
520 |
755 |
520 |
628 |
24" 600mm |
620 |
755 |
620 |
680 |
620 |
780 |
620 |
695 |
620 |
840 |
620 |
735 |
620 |
0 |
620 |
745 |
|
